Single Station eva forming machine

Single Station eva forming machine
Single Station eva forming machine
Send Inquiry
Product Code : 03
Product Description

Based in Delhi, India, we are a reputed and established firm involved in manufacturing and supplying excellent quality Single Station Eva Forming Machine. Our professionals make use of quality tested raw materials to make these machines in full compliance with international quality standards. It is widely used in footwear industries for making single and double color EVA sole, slippers, and parts of toys. Owing to its vertical clamping, it occupies less space and able to work continuously without any issues. Offered Single Station Eva Forming Machine is highly appreciated by our clients for its excellent production capacity, high operational fluency, robust construction, and many other attributes.



Single Station eva forming machine :
Features:

  • RAM EVALITE - I is designed for making EVA soles for ladies and gents footwear, and extensively used in toy industry for making Toy Cycle Tyres and other EVA product of different colours and size.
  • Sturdy design and simplicity in operation.
  • Machine has vertical clamping hence uses very less space.
  • Mould Space : It is easy to match with various kind of mould and reduces limitations of mould design.
  • Temperature controlled by three temprature controllers: Gives perfection in maintaining the melt Temp. with least variation.
  • Ergonomically designed and inter changeability.
Technical Specifications:
Mould Clamping Unit Single Station
Production Capacity 80 pairs / hour
Station Size 560 X 760 mm
Cylinder Size 355 mm
Station Opening 430 mm each
Clamping Force 150 Ton
Clamping Pressure 120 Bar
Hyd Pump Displacement 120 lpm
Motor for Pressure Pump 5 HP / 960 rpm
Motor for Pressure Release 2 HP / 1440 rpm
Electrical Heater 12 X 1.5 kw
Floor Area of Machine 915 X 2185 X 2185
Weight of Machine 2500 kg
